Editor Overlay

The editor overlay lets you edit shader code directly on top of the preview canvas. It uses a Monaco editor with GLSL syntax highlighting and a semi-transparent background so you can see the shader output while you type.

Opening

  • Click the Editor icon (code brackets) in the toolbar
  • Or select Editor from the options menu
  • Or run Shader Studio: Toggle Editor Overlay from the command palette

Editor overlay active Placeholder: feature-editor-overlay.png — Editor overlay open on top of the shader preview with Monaco editor content visible.

Features

  • GLSL syntax highlighting with custom shader-studio theme
  • Line numbers with current line highlight
  • Error markers — red squiggly underlines on lines with compilation errors, hover for full error message
  • Live recompile — 30ms debounce on edits for near-instant preview updates
  • File sync — 500ms debounce to save changes back to the file
  • Position preservation — cursor position and scroll are maintained when switching buffers

Buffer Tabs

When your shader has multiple passes (Image, BufferA, BufferB, Common, etc.), each appears as a tab along the top of the overlay. Click a tab to switch to that buffer.

  • Close (×) on a tab removes that buffer pass from the config
  • Double-click a tab to navigate to that file in the VS Code editor (requires shader lock to be on)
  • Buffer selection syncs with the config panel

Adding Passes from the Overlay

Click the + button in the tab bar to add a new pass:

Option Description
Buffer Add a new render pass (BufferA–D)
Common Add a shared GLSL code pass (only one allowed)
Script Add a custom uniforms script file (only one allowed)

Vim Mode

Toggle Vim mode from the options menu → Vim Mode. When active, a Vim status bar appears at the bottom of the overlay.

Editor overlay with Vim mode Placeholder: feature-editor-vim.png — Editor overlay with Vim mode status bar visible at the bottom showing the current mode (NORMAL/INSERT).

Vim Commands

Command Action
:bnext / :bn Switch to next buffer
:bprev / :bp Switch to previous buffer
:buffer name / :b name Jump to named buffer
:lnext / :lne Jump to next error
:lprev / :lp Jump to previous error

Vim Key Mappings

Key Action
]d Next diagnostic/error
[d Previous diagnostic/error
gl Show hover (error tooltip)
